Cylinder accessories

Stainless steel cylinders

Adaptor for cylinder

Ø25 mm - Ø125 mm, AISI 304 (EN 1.4301), Wiper PTFE

*Available in AISI 316L (EN 1.4404), Wiper PTFE

	Adaptor A1	Adaptor A2
Ø25 Ø32 Ø40 Ø50 Ø63 Ø80 Ø100 Ø125	U1902548-48 U1903248-48 U1904048-48 U1905048-48 U1906348-48 U1908048-48 U1910048-48 U1912548-48	U1902549-48 U1903249-48 U1904049-48 U1905049-48 U1906349-48 U1908049-48 U1910049-48 U1912549-48

Stainless steel cylinders

Neck nut

Ø12 mm - Ø125 mm

Ø12/16
Ø20/25
Ø32
Ø40
Ø50/Ø63
Ø80/Ø100
Ø125

U1901402
U1902502
U1903202
U1904002
U1905002
U1909002
U1912502

Stainless steel cylinders

Piston rod nut

Ø12 mm - Ø125 mm

Ø12/16
Ø20
Ø25/32
Ø40
Ø50/63
Ø80/100
Ø125

U1901430
U1902030
U1903030
U1904030
U1905930
U1909030
U1912530

Rod eye

Ø12 mm - Ø125 mm | DIN/ISO 8139

Ø12/16
Ø20
Ø25/32
Ø40
Ø50/63
Ø80/100
Ø125

U1901427
U1902027
U1903027
U1904027
U1905927
U1909027
U1912527

Stainless steel cylinders

Rod clevis

Ø12 mm - Ø125 mm | DIN/ISO 8140

Ø12/16
Ø20
Ø25/32
Ø40
Ø50/63
Ø80/100
Ø125

U1901423
U1902023
U1903023
U1904023
U1905923
U1909023
U1912523

Stainless steel cylinders

Foot mounting

Ø12 mm - Ø25 mm | DIN/ISO 6432

Ø12/16
Ø20/25

U1901407
U1902307

Counter-support

Ø12 mm - Ø25 mm | DIN/ISO 6432

Ø12/16
Ø20/25

U1901403
U1902303

Counter-support

Ø32 mm - Ø125 mm | DIN/ISO 15552

Ø32
Ø40
Ø50
Ø63
Ø80
Ø100
Ø125

U1903212E
U1904012E
U1905012E
U1906312E
U1908012E
U1910012E
U1912512E

Clevis mounting, slim

Ø32 mm - Ø125 mm | DIN/ISO 15552

Ø32
Ø40
Ø50
Ø63
Ø80
Ø100
Ø125

U1903210E
U1904010E
U1905010E
U1906310E
U1908010E
U1910010E
U1912510E

Anti-rotation bolt - for slim clevis mounting

Ø32 mm - Ø125 mm | DIN/ISO 15552

Ø32
Ø40
Ø50
Ø63
Ø80
Ø100
Ø125

U1903211E
U1904011E
U1905011E
U1906311E
U1908011E
U1910011E
U1912511E

Counter-support 90°

Ø32 mm - Ø125 mm | DIN/ISO 15552

Ø32
Ø40
Ø50
Ø63
Ø80
Ø100
Ø125

U1903213E
U1904013E
U1905013E
U1906313E
U1908013E
U1910013E
U1912513E

Counter with rod eye

Ø32 mm - Ø125 mm | DIN/ISO 15552

Ø32
Ø40
Ø50
Ø63
Ø80
Ø100
Ø125

U1903219E
U1904019E
U1905019E
U1906319E
U1908019E
U1910019E
U1912519E

Stainless steel cylinders

Bolt for clevis

Ø32 mm - Ø125 mm | DIN/ISO 15552

Ø32
Ø40
Ø50
Ø63
Ø80
Ø100
Ø125

U1903215
U1904015
U1905015
U1906315
U1908015
U1910015
U1912515

Stainless steel cylinders

Swivel bearing - set

Ø32 mm - Ø125 mm | DIN/ISO 15552

Ø32
Ø40
Ø50
Ø63
Ø80
Ø100
Ø125

U1903216
U1904516
U1904516
U1907016
U1907016
U1911016
U1911016

Stainless steel cylinders

Pivot attachment

Ø32 mm - Ø125 mm | DIN/ISO 15552

Ø32
Ø40
Ø50
Ø63
Ø80
Ø100
Ø125

U1903217
U1904017
U1905017
U1906317
U1908017
U1910017
U1912517

Stainless steel cylinders

Reed sensor

Reed switch, synthetic, IP 67, w/o cablel

reed sensor

Accessories for reed sensor

Bracket for reed switches for cylinders Ø12 - Ø125
